智能功能，高質量的圖像
DP23顯微鏡相機結合了高圖像質量、色彩準確性和方便的功能，使您的工業檢查工作流程更容易。提供先進的功能與高價值的平衡，DP23相機可以執行幾乎任何工業成像應用。在檢查過程中，花更少的時間在樣品周圍掃描，花更多的時間評估你在屏幕上看到的東西
顯微鏡攝像頭DP23數碼相機技術規格：
DP23 specifications：
|
Microscope Camera Mount |
C-mount |
|
|
Image Sensor |
System |
Color CMOS Camera |
|
Size |
1/1.8 in. Color CMOS |
|
|
Pixel Size |
6.4 megapixel |
|
|
Scanning Method |
Progressive scanning |
|
|
Shutter Type |
Rolling shutter*1 |
|
|
Maximum Recording Pixel |
3088 x 2076 Full Resolution |
|
|
Movie Frame Rate |
Up to 60fps Full HD |
|
|
Exposure time |
Auto：13 μs to 15 s |
|
|
Camera I/F |
USB3.1 Type-C® |
|
|
Dimensions |
76.7（W） × 70.1（D） × 37.3（H）mm |
|
|
Weight |
380g |
|
|
Interface |
Display output: 2 × HDMI |
|
|
Scale display |
Scale bar supported |
|
|
Measuring functions*3 |
Measurement function count, distance between 2 points, polyline, 3-point circle, rectangle, 3-point angle, 4-point angle, perpendicular, area and perimeter of polygon, distance between 2 centers, ruler |
|
*1 OLYMPUS
Stream Instant MIA cannot be used because image distortion may occur when
moving the stage
*2 USB 3.1 Gen1 is compatible with USB 3.0
*3 The DP23-AOU configuration only
